Detail
Model | C1022 | C1522 | C2022 | C1027 | C2522 | C3022 | |
|---|---|---|---|---|---|---|---|
| Standard | GB7247.1/4/13、EN60825-1/4、IEC60825-1/13 | ||||||
| Protective Exposure Limit | Basic：0.9mm thick,PEL=42.08W/cm²,test wavelength 1070nm,spot diameter 5mm,test time T=100s,TR 550℃ Expert：0.7mm thick,PEL=566.5W/cm²,test wavelength 1070nm,spot diameter 3mm,test time T=100s,TR 1200℃ | ||||||
| Laser Type | All types of lasers from 190 to 11000nm | ||||||
| Laser Damage Phenomenon | Produce white smoke | ||||||
| Frame Size(L×H) | 0.9×2.2m | 1.4×2.2m | 1.85×2.2m | 2.35×2.2m | 2.85×2.2m | ||
| Cloth Size(L×H) | 1.0×2.06m | 1.5×2.06m | 1.0×2.06m,2PCS | 1.0×2.06m 1.5×2.06m | 1.5×2.06m,2PCS | ||
| Materials | Composite material with special coating | ||||||
| Configuration | Hanging hole, laser safety mark, Velcro | ||||||
| Feature | Excellent heat and flame resistance, low reflection, wear resistance | ||||||
| Applicable Place | Class 4 laser protection places, laser laboratories, laser equipment, laser processing workshops | ||||||
| Installing Form | Free movement, can be spliced to form a "I", "L", "U" and "O" shape | ||||||
