Details
ADF Model | LY200L | ||
|---|---|---|---|
| Optical Class | 1/1/1/3 | 1/1/1/2 or 1/1/1/1 | |
| Cartridege Size | 146×56.7×19mm | 108×51×8.2mm | |
| Viewing Area | 109mm×32.5mm ( 4.29” x 1.28” ) | 93×34m("×") | |
| Light State | DIN3 | DIN3.5 | |
| Dark State | DIN11 | DIN8～13 | |
| Shade Control | No | Internal & Stepless | |
| Switching Time | 3/10000S±20% | 2/10000S±20% | |
| Sensitivity Control | No | Internal & Stepless | |
| Delay Time | 0.2S | 0.1S～1S | |
| Power Supply | Li-battery & Solar | Li-battery & Solar | |
| Rated Capacity Of Li-Battery | 60mAh | 60mAh | |
| Replaceable Battery | No | Yes | |
| Operating Temp. | -5℃～55℃ | -5℃～55℃ | |
| Storing Temp. | -20℃～70℃ | -20℃～70℃ | |
| Arc Sensor | 2 | 2 | |
| Low Amperage TIG Rated | ≥30amps | ≥5amps | |
| Helmet Material | PC / ABS | PP or PA | |
| UV/IR Protection | DIN11 | DIN13 | |
| Test | No | No | |
| Low Battery | No | Yes | |
| Grinding | No | No | |
| Cuting | No | No | |
| LED | x | No | |
PACKAGING & SHIPPING
1) Wrap the glasses in a plastic bag
2) Put the glasses wrapped in plastic bag into the color box
3) Put 50Pcs of glasses in color boxes into the master carton
